| Description | Model | Quantity |
|
|
1 | 6 Axis Welding Robot | Model：KLTZ1520 | 1 set |
|
|
3*AC380 V ,50/60HZ |
R=1507mm，Load=6kg |
Control cabinet:TRC3C-B06 |
Anti-collision welding torch:APG35Y |
Cable Line:Standard configuration |
Wire Touch Sense System，Wire inspection,Workpiece inspection,Workpiece offset compensation |
2 | MIG/MAG/CO2 Welding Power | Model: Panasonic YD-350GL5 Load rate: 60% ;MIG/MAG/CO2;Robot special wire feeder | 1 set |
|
|
3 | Double station platform | Fixed platform table size: 500mm*500mm | 1 set |
|
|
4 | Welding gun clearing station | Clean up the torch, fuel injection, cut the wire （3 in 1） Chinese brand | 1 set |
|
|
5 | Protective peripheral parts | Includes: protective fence, external start button, raster protection, cable line bridge and cable wire required for the workstation | 1 set |
|
|
|
|
|
|
|
|
