盐城市科力特焊割设备有限公司

YANCHENG CITY KELITE WELDING EQUIPMENT CO., LTD.                              E-mail:Jason_Jiang@kltweld.com

Description

Model

Quantity

1

6 Axis Welding Robot

Model：KLTW1900

3set

3*AC380 V ,50/60HZ

R=1898mm，Load=6kg

Control cabinet: TRC3C-B06

R axis travel: 0-400 degrees

Anti-collision welding torch: APG35Y

Touch Sense System

Cable Line: Standard configuration

2

MIG/MAG/CO2       Welding Power

Model: Panasonic YD-350GL5

Load rate: 60% ;MIG/MAG/CO2

Contain: Wire feeder , Control cable

3set

3

Servo positioner system

Load≤500kg, Linked with the robot,

Platform size 1900 *1900mm, Precision RV reducer, External start button box, does not include fixtures

3 set

4

Gun gun cutting system

Clean up the torch, fuel injection, cut the wire

（3 in 1） Chinese brand

3 set

5

Conductive tip

Φ=1.0mm orΦ=1.2mm

1 row = 10 pieces

50 row

6

Welding torch cover

350A Air-cooled welding torch ;

1 row = 5 pieces

50 row

7

Port fees

Container port costs

1 set
